Eurolite DMX Split 8X

8-Way DMX Splitter!
  • Splits a single DMX input into 8 DMX outputs
  • Additional QuickDMX input for wireless DMX reception
  • Inputs & outputs galvanically isolated
  • Connections: 3-pin & 5-pin XLR
  • Each DMX output with independent driver & data LED
  • Inputs & outputs with internal 500-mA fuse
  • 19" Rackmount
Variants (5)
Eurolite DMX Split 2 Splitter 3/5-Pin
Eurolite DMX Split 4 Splitter
Eurolite DMX Power Splitter 2x2
Eurolite DMX Split 8X Splitter 3-pin
Eurolite DMX Split 6X
Eurolite DMX Split 2 Splitter 3/5-Pin Eurolite DMX Split 2 Splitter 3/5-Pin
Eurolite DMX Split 2 Splitter 3/5-Pin
  • Compact splitter with 3- & 5-pin XLR connectors
  • LED status indicators
  • Fixed power cable
  • Sturdy metal housing with M10 threaded inserts
RRP** 54,62
42,60
Eurolite DMX Split 4 Splitter Eurolite DMX Split 4 Splitter
Eurolite DMX Split 4 Splitter
  • Distributes one DMX input to 4 DMX outputs
  • Input and outputs galvanically isolated
  • Each DMX output with independent driver & status indicators
  • Input and outputs with internal 500 mA fuse
  • Switchable termination resistor
RRP** 106,98
92,70
Eurolite DMX Power Splitter 2x2
  • Reliable Power & DMX Splitter
  • 1 P-Con input to 2 outputs, max. 10 A
  • 1 DMX input to 2 outputs
  • Inputs & outputs are galvanically isolated
  • LED status indicators for Signal In/Out
  • Durable metal housing with M10 threaded insert
RRP** 95,08
95
Eurolite DMX Split 8X Splitter 3-pin Eurolite DMX Split 8X Splitter 3-pin
Eurolite DMX Split 8X Splitter 3-pin
  • DMX splitter for distributing a DMX input signal to 8 DMX outputs
  • Input and output galvanically isolated
  • Switchable termination resistor
  • 19" rackmount 1U
  • Each DMX output with an independent driver and status indicator
  • Passive convection cooling
RRP** 117,81
99
Eurolite DMX Split 6X Eurolite DMX Split 6X
Eurolite DMX Split 6X
  • Splits a DMX input into 6 DMX outputs
  • Inputs & outputs galvanically isolated
  • Connections: 3-pin & 5-pin XLR
  • Each DMX output with independent driver & data LED
  • Input & outputs with internal 500 mA fuses
  • 19\" rackmount
RRP** 177,31
127
-7% 209
instead of RRP**224,91
All prices include VAT
Ready for shipping
Finance from 23,00 € per month
Standard Shipping
free
Delivery time 8 - 9 working days
Shipping and Delivery
Get personal advice now!

Our specialists from the Live & Studio department are looking forward to your call.

08861-909494-6

[email protected]

Splitter With 8 Galvanically Isolated Outputs, 3/5-Pin & QuickDMX XLR Sockets!

Enjoy minimal risk and maximum performance. Two features cut the risk: the DMX chain is split into eight runs, and because all outputs are galvanically isolated, a single faulty cable won't take down the whole system. An additional QuickDMX input enables wireless reception of DMX signals. When uninterrupted lighting performance matters on large stages and big installations, this DMX splitter is an absolute must.

Quality Accessories Made in Germany!

Features

  • DMX splitter to distribute a DMX input signal to 8 DMX outputs
  • Connections: 1 x DMX input, 1 x DMX thru output, 8 x DMX outputs
  • Additional QuickDMX input for wireless DMX reception
  • Inputs and outputs: both 3-pin and 5-pin XLR
  • Inputs and outputs galvanically isolated
  • Each DMX output has an independent driver and status indicators
  • Inputs and outputs with internal 500-mA fuse
  • Switchable termination resistor
  • 19" Rackmount
  • Power Supply: 100-240 V AC, 50/60 Hz
  • Total power consumption: 5 W
  • Dimensions (L x W x H): 48,3 x 4,45 x 14,5 cm
  • Weight: 2,0 kg

Scope of delivery

  • 1 x Eurolite DMX Split 8X

Specification

  • Product number 00063738
  • Colour Black
