Splitter To 6 Galvanically Isolated Outputs, 3-Pin & 5-Pin XLR Sockets!
Minimal risk and maximum enjoyment are guaranteed. Two factors reduce the risk: a DMX line is split into six runs, and because all outputs are galvanically isolated, a single faulty cable won’t take down the whole system. When uninterrupted lighting performance matters on large stages and in big installations, this DMX splitter is a must-have.
Quality Accessories Made in Germany!
Features
- DMX distributor for splitting a DMX input signal into 6 DMX outputs
- Input and outputs galvanically isolated
- Connections: 3-pin and 5-pin XLR
- Each DMX output with independent driver and data LED
- Input and outputs protected by internal 500 mA fuses
- 19\" rackmount
- Power supply: 230 V AC, 50 Hz ~
- Total power consumption: 35 W
- DMX512 output: 3-pin or 5-pin XLR chassis connector
- Dimensions (LxWxH): 483 x 200 x 50 mm
- Weight: 3.5 kg
Scope of delivery
- 1x Eurolite DMX Split 6X
Specification
- Product number 00019738
- Colour Black
