Omnitronic CPZ-120P ELA Mixing Amplifier

4-Zone ELA Mono Mixing Amplifier with MP3 Player!

4 ELA zone outputs, individually switchable from the front panel
Master ELA speaker output (70 and 100 V)
Connection option for low-impedance speakers (4-16 Ohm)
Integrated audio player with Bluetooth® receiver and IR remote control
Wireless music streaming from your devices (e.g., smartphone, tablet) via Bluetooth®
SD card slot and USB port

Omnitronic CPZ-60P PA Mixer-Amplifier

4 PA zone outputs, individually switchable on the front panel
Master PA speaker output (70 and 100 V)
Connection option for low-impedance speakers (4-16 Ohm)
Integrated audio player with Bluetooth receiver and IR remote control
Wireless music streaming from your devices (e.g., smartphone, tablet) via Bluetooth
SD card slot and USB port

RRP** 213,01 €

164 €

-25% 259 €

instead of RRP**: 343,91 €

All prices include VAT

Ready for shipping

Standard Shipping

Delivery time 8 - 9 working days

ELA Mono Mixing Amplifier With 60–120 Watts of Power and Audio Player!

The amplifiers of the CPZ series are specially designed for use in ELA public address systems. Four 100 V outputs are available for four coverage zones, which can be switched on and off independently.

The additional direct outputs allow the connection of ELA speakers with 100 V audio transformers or low-impedance speakers (4-16 Ohm). The five mixable inputs accept microphones and line-level devices. Microphone channel 1 includes a priority circuit that reduces the volume of other signal sources during an announcement. Music from smartphones, tablets and computers can be streamed wirelessly via Bluetooth® to the integrated audio player. An FM tuner and slots for USB and SD(HC) storage media are also provided. The audio player can be conveniently controlled via the remote control.

Installation in ELA Systems Must Be Performed by Qualified Personnel!

Features

4 ELA zone outputs, individually switchable from the front panel
Master ELA speaker output (70 and 100 V)
Connection option for low-impedance speakers (4-16 Ohm)
Integrated audio player with Bluetooth® receiver and IR remote control
Wireless music streaming from your devices (e.g., smartphone, tablet) via Bluetooth®
SD card slot and USB port
FM tuner with auto scan
3 microphone inputs with separate volume controls
Mic 1 with phantom power, priority function and echo effect
Mic 2 and 3 switchable Mic/Line
2 line inputs with separate volume controls
1 line output
Siren and chime, adjustable
Bass, treble and master controls for the output signal
5-segment LED level indicator
Protection circuits with LED indicators: overload, short circuit, clip limiter, overheating
Fan-cooled
Mains and 24 V emergency power operation
Tabletop housing
Controllable via Bluetooth®; IR remote control included

Technical Data

Power supply: 100-240 V AC, 50/60 Hz or 24 V
Total power consumption: 240 W
Output power: 120 W RMS
Power connection: IEC mains input; power cable with protective-earth plug included for built-in version, or battery/accumulator (not included)
Battery: 1 x CR2025 3.0 V button cell (lithium-manganese) installed
Impedance: 1 x 4 Ohm; 1 x 8 Ohm; 1 x 16 Ohm; 1 x ELA 100 V
Control: Bluetooth®; IR remote control included
Audio player: USB + SD + Bluetooth® + FM radio
Zone outputs: 4 switchable zones
Circuit: Class D
Master EQ: 1 x 2-band control
Inputs: 1 x microphone via 3-pin XLR, 2 x Mic/Line via 6.3 mm jack (stereo) built-in version, 2 x line via stereo RCA
Outputs: 1 x line via stereo RCA 0.774 V, speakers via screw terminal
Music format: MP3
Form factor: 2U
Dimensions (W x D x H): 30.3 x 22 x 9.1 cm
Weight: 3.95 kg
