PA Mono Mixer-Amplifier With 120 W Output and Audio Player!
The CPE-series amplifiers are specifically designed for use in PA sound systems.
It offers outputs for PA speakers with 70 V or 100 V line transformers, or for 4-16 Ohm low-impedance speakers. The five mixable inputs accept microphones and line-level devices. Microphone channel 1 features a priority circuit that reduces the volume of other sources during an announcement. Music from smartphones, tablets and computers can be streamed wirelessly via Bluetooth to the built-in audio player. An FM tuner and slots for USB and SD(HC) storage media are also provided. The audio player can be conveniently controlled with the included remote control.
Installation in PA Systems Must Be Performed by Qualified Personnel!
Features
- Outputs for 70 V or 100 V PA speakers
- Outputs for low-impedance speakers (4-16 Ohm)
- Integrated audio player with Bluetooth receiver and IR remote control
- Wireless music streaming from your devices (e.g. smartphone, tablet) via Bluetooth
- SD card slot and USB port
- FM tuner with auto-scan
- 3 microphone inputs with separate volume controls
- Mic 1 with phantom power and priority function
- Mic 2 and 3 switchable Mic/Line
- 2 line inputs with separate volume controls
- 1 line output
- Bass, treble and master controls for the output signal
- 4-segment LED level meter
- Protection circuits with LED indicators: overload, short circuit, clip limiter, overheating
- Mains and 24 V emergency power operation
- Desktop chassis
- Controllable via Bluetooth; IR remote control included
- 2 U
Technical Specifications
- Power supply: 230 V AC, 50 Hz or 24 V
- Total power consumption: 240 W
- Output power: 120 W RMS
- Battery: 1 x CR2025 3.0 V lithium-manganese coin cell (built-in)
- Power connection: Mains input via IEC connector (male). For built-in version, power cable with mains plug included; battery/accumulator (not included)
- Impedance: 1 x 4 Ohm, 1 x 8 Ohm, 1 x 16 Ohm, 1 x 100 V PA
- Control: Bluetooth, IR remote control included
- Audio player: USB + SD + Bluetooth + FM radio
- Amplifier type: Class D
- Equalizer: Master: 1 control, 2-band
- Connections:
- Input: 1 x microphone via 3-pin XLR
- Input: 2 x Mic/Line via 6.3 mm jack (stereo) built-in version
- Input: 2 x Line via stereo phono
- Output: 1 x Line via stereo phono 0.774 V
- Output: Speakers via screw terminal - Music format: MP3
- Enclosure type: 2 U
- Dimensions (W x D x H): 30.3 x 22 x 9.1 cm
- Weight: 3.96 kg
Scope of delivery
- 1 x Omnitronic CPE-120P PA mixer-amplifier
- 1 x remote control
Specification
- Product number 00116868
- Colour Schwarz
- Microphone input Ja, mit Phantomspeisung
- Power (Watts) 120
