Omnitronic CPZ-60P PA Mixer-Amplifier

4-Zone PA Mono Mixer-Amplifier with MP3 Player!

4 PA zone outputs, individually switchable on the front panel
Master PA speaker output (70 and 100 V)
Connection option for low-impedance speakers (4-16 Ohm)
Integrated audio player with Bluetooth receiver and IR remote control
Wireless music streaming from your devices (e.g., smartphone, tablet) via Bluetooth
SD card slot and USB port

Omnitronic CPZ-120P ELA Mixing Amplifier

Omnitronic CPZ-120P ELA Mixing Amplifier

4 ELA zone outputs, individually switchable from the front panel
Master ELA speaker output (70 and 100 V)
Connection option for low-impedance speakers (4-16 Ohm)
Integrated audio player with Bluetooth® receiver and IR remote control
Wireless music streaming from your devices (e.g., smartphone, tablet) via Bluetooth®
SD card slot and USB port

RRP** 343,91 €

259 €

-23% 164 €

instead of RRP**: 213,01 €

All prices include VAT

Ready for shipping

Standard Shipping

Delivery time 8 - 9 working days

PA Mono Mixer-Amplifier With 60 Watts of Power and Audio Player!

The amplifiers of the CPZ series are specially designed for use in PA sound systems. There are 100 V outputs for four coverage zones available, which can be switched on and off separately.

The additional direct outputs allow connection of PA speakers with 100 V audio transformers or low-impedance speakers (4-16 Ohm). Five mixable inputs accept microphones and line-level devices. Microphone channel 1 features a priority circuit that reduces the volume of the other signal sources during an announcement. Music from smartphones, tablets and computers can be streamed wirelessly to the integrated audio player via Bluetooth. An FM tuner as well as slots for USB and SD(HC) storage media are also provided. The audio player can be conveniently controlled via remote control.

Installation in PA systems must be carried out by qualified personnel!

Features

4 PA zone outputs, individually switchable on the front panel
Master PA speaker output (70 and 100 V)
Connection option for low-impedance speakers (4-16 Ohm)
Integrated audio player with Bluetooth® receiver and IR remote control
Wireless music streaming from your devices (e.g., smartphone, tablet) via Bluetooth®
SD card slot and USB port
FM tuner with auto scan
3 microphone inputs with separate volume controls
Mic 1 with phantom power, priority function and echo effect
Mic 2 and 3 switchable Mic/Line
2 line inputs with separate volume controls
1 line output
Siren and gong, adjustable
Bass, treble and master controls for the output signal
5-segment LED level meter
Protection circuits with LED indicators: overload, short circuit, clip limiter, overheating
Fan-cooled
Mains and 24 V emergency power operation
Desktop chassis
Controllable via Bluetooth®; IR remote included

Technical Data

Power supply: 100-240 V AC, 50/60 Hz or 24 V
Total power consumption: 120 W
Output power: 60 W RMS
Power connection: mains input via IEC inlet (male); rackmount version: power cable with protective earth plug included or battery/accumulator (not included)
Battery: 1 x CR2025 button cell 3.0 V (lithium-manganese) installed
Impedance: 1 x 4 Ohm; 1 x 8 Ohm; 1 x 16 Ohm; 1 x PA 100 V
Control: Bluetooth; IR remote control included
Audio player: USB + SD + Bluetooth® + FM radio
Zone outputs: 4 switchable zones
Circuit: Class D
Equalizer: Master: 1 x 2-band control
Inputs: 1 x microphone via 3-pin XLR, 2 x Mic/Line via 6.3 mm jack (stereo) rackmount version, 2 x line via stereo phono
Outputs: 1 x line via stereo phono 0.774 V, speakers via screw terminal
Music format: MP3
Enclosure size: 2 U
Dimensions (W x D x H): 30.3 x 22 x 9.1 cm
Weight: 3.6 kg
