PA Mono Mixer Amplifier with 40 Watt Power and Audio Player!
The amplifiers of the CPE series are specially designed for use in PA sound systems.
Outputs are available for PA speakers with 70-V and 100-V audio transformers or 4-16 Ohm speakers. Five mixable inputs allow connection of microphones and devices with line level. Microphone channel 1 features a priority circuit that lowers the volume of other signal sources during announcements. Music from smartphones, tablets, and computers can be easily streamed wirelessly via Bluetooth to the built-in audio player. An FM tuner and slots for USB and SD(HC) storage media are also included. The audio player can be conveniently controlled via remote control.
Installation in PA systems must be carried out by qualified personnel!
Features
- Connections for 70-V or 100-V PA Speakers
- Connections for Low-Impedance Speakers (4-16 Ohm)
- Built-in Audio Player with Bluetooth® Receiver and IR Remote Control
- Wireless Music Streaming from Your Music Devices (e.g. Smartphone, Tablet) via Bluetooth®
- SD Card Slot and USB Port
- FM Tuner with Auto Scan
- 3 Microphone Inputs with Separate Volume Controls
- Mic 1 with Phantom Power and Priority Function
- Mic 2 and 3 Switchable Mic/Line
- 2 Line Inputs with Separate Volume Controls
- 1 Line Output
- Bass, Treble, and Master Controls for the Output Signal
- 4-LED Level Meter
- Protection Circuits with LED Indicators: Overload, Short Circuit, Clip Limiter, Overheating
- Power Supply and 24-V Emergency Power Operation
- Desktop Housing
- Controllable via Bluetooth®; IR Remote Control Included
- 2 RU
Technical Data
- Power Supply: 230 V AC, 50 Hz or 24 V
- Total Power Consumption: 80 W
- Output Power: 40 W RMS
- Battery: 1x CR2025 Button Cell 3.0 V Lithium Manganese Installed
- Power Connection: Power Supply Cold Device (M) Built-in Version Power Cable with Protective Contact Plug Included, Battery/Accumulator (not included)
- Impedance: 1x 4 Ohm, 1x 8 Ohm, 1x 16 Ohm, 1x 100 V PA Technology
- Control: Bluetooth®, IR Remote Control Included
- Audio Player: USB + SD + Bluetooth® + FM Radio
- Circuit: Class D
- Equalizer: Master: 1 Control 2-Band
- Connections:
- Input: 1 x Microphone via 3-pin XLR
- Input: 2 x Mic/Line via 6.3 mm Jack (stereo) Built-in Version
- Input: 2 x Line via Stereo RCA
- Output: 1 x Line via Stereo RCA 0.774 V
- Output: Speaker via Screw Terminal - Music Format: MP3
- Housing Type: 2 RU
- Dimensions (W x D x H): 30.3 x 22 x 9.1 cm
- Weight: 2.73 kg
Scope of delivery
- 1 x Omnitronic CPE-40P PA Mixer Amplifier
- 1 x Remote Control
Suitable accessories (Not included in the delivery.)
Specification
- Product number 00075554
- Power (Watts) 40
- Microphone input Yes, with phantom power
- Colour Black
