Omnitronic MAXX-1206DSP 2.1 Active System - Compact and Powerful!
The MAXX-1206DSP is an active 2.1 PA system delivering 450 watts for a wide range of mobile applications. This compact PA impresses with its high-quality sound and strong level stability.
The powerful 12" subwoofer with a highly efficient Class-D amplifier in a bass reflex enclosure delivers strong, tight bass. The two satellite speakers with 6.5" mid-woofers and 1" compression drivers feature a passive 2-way crossover including a PTC tweeter protection, providing a well-rounded sound experience.
Besides the DSP (digital signal processor) with handy presets for quick, application-specific sound tuning, combined XLR and 6.3 mm jack inputs with XLR parallel output (for additional systems) and an extra RCA input with level adjustment are available. Thanks to integrated Bluetooth audio streaming, you can enjoy music wirelessly directly from your smartphone or any other Bluetooth device, and the built-in USB port lets you conveniently charge your mobile devices at the same time.
The MAXX-1206DSP subwoofer is professionally equipped with a sturdy enclosure made of multiplex and MDF wood, textured paint, metal grille, and ergonomic handles.
Features
- Mobile 2.1 system with DSP and 450 Watt RMS power
- Delivers high-quality sound and strong level stability for a variety of mobile sound reinforcement applications up to medium-sized events - ideal for solo entertainers, bands, and mobile discos
- 12" subwoofer with Class-D amplifier in bass reflex enclosure delivers powerful, tight bass
- Two satellites with 6.5" mid-woofers and 1" compression drivers
- Satellites with passive 2-way crossover including PTC tweeter protection
- Balanced signal input XLR/6.3 mm jack L/R
- Additional stereo RCA input with level adjustment
- Parallel XLR output L/R for linking additional active speakers
- Integrated Bluetooth audio streaming for wireless music enjoyment from your music devices (e.g. smartphone, tablet PC)
- 3 EQ presets with status indicators, DSP controlled
- Signal limiter, DSP controlled
- Separate volume control for subwoofer and satellites
- Stereo-mono switch
- Integrated fast charging unit (5 V/2 A) for convenient charging of mobile USB devices
- Enclosure made of 16 mm thick MPX/MDF (subwoofer) and MDF (satellites) with durable textured paint and metal grille
- Subwoofer with M20 metal flange for mounting a satellite
- Delivery includes two speaker cables
Tweeters
- 2-way bass reflex system with 6.5" mid-woofer and 1" titanium compression driver
- With passive 2-way crossover including PTC tweeter protection
- With rigging points
- Black metal grille with acoustic foam
- Robust carrying handle
- Usage options: standing; flying; monitoring; on stand
- Power handling: 200W (program), 100W RMS (nominal)
- Frequency range: 100 - 17000 Hz
- Sensitivity: 91 dB
- Max. sound pressure: 115 dB
- Dispersion: 90° x 60°
- Impedance: 4 Ohm
- Mounting system: 35mm flange
- Rigging points: 3x M8 thread
- Connections: 1 x speaker built-in socket (W)
- Basket material: steel
- Cone material: cardboard/paper
- 1 carrying handle:
- Material: MDF (medium-density fiberboard), 16 mm
- Color: black, textured surface, painted
- Dimensions (WxHxD): 20.4 x 36.2 x 19 cm
- Weight: 12.7 kg each
Subwoofer
- 12" subwoofer with Class-D amplifier in bass reflex enclosure
- Amplifier power: 250 W RMS + 2 x 100 W RMS for two satellite speakers
- Balanced signal input XLR/6.3 mm jack L/R
- Additional stereo RCA input with level adjustment
- Separate volume control for subwoofer and satellites
- Stereo-mono switch
- Digital signal processor
- Controllable via Bluetooth
- Rubber feet
- DSP presets: FLAT; DJ; LIVE
- Black metal grille with acoustic foam
- Power supply: 230 V AC, 50 Hz
- Total power consumption: 500 W
- Protection class: SK I
- Power connection: power supply via cold device (male) built-in version power cable with protective contact plug included
- Device fuse: 5 x 20 mm, T 4 A replaceable fuse
- Power handling: Nominal: 250W RMS LF
- Nominal: 2x 100W RMS HF
- Frequency range: 38 - 250 Hz bass
- Sensitivity: 97 dB
- Max. sound pressure: 119 dB
- Mounting system: M20 thread
- Circuit: Class D
- Controls: power switch, volume control, input sensitivity switch, connect, tone control
- Protection circuit: limiter
- Status LED: power, signal, limit, pairing, DSP presets
- Inputs: line (stereo RCA), line 2x combo jack, Bluetooth
- Outputs: line (2x XLR), speaker (2x speaker built-in socket)
- Speakers: 1 x woofer (12") with ferrite magnet
- Basket material: steel
- Cone material: cardboard/paper
- USB port: 1 x type C, 2 A
- Design: bass reflex
- Transport aid: rubber feet
- Material: MDF (medium-density fiberboard), 16 mm
- Color: black, textured surface, painted
- Dimensions (WxHxD): 38.4 x 45.8 x 47.4 cm
- Weight: 19.1 kg
Scope of delivery
- 1 x subwoofer
- 2 x tweeters
- 1 x power cable
- 1 x strap
- 2 x speaker cables
Specification
- Product number 00103281
- Power RMS (Watts) 450
- Configuration 2.1
- With mixing desk/power mixer No
- Colour Black
- Satellites/Fullrange 6,5 Zoll/1 Zoll
- Inputs 6.3mm Klinke, Bluetooth, Cinch / RCA, XLR
- Subwoofers 1x 12 Zoll
