TMH-H90 - Spot & Washlight In One Unit!
Spotlight and washlight: the TMH-H90 from Eurolite is both. Inside it’s a full-featured spotlight packed with options, and around its lens sit six powerful 10W LEDs with 6-color mixing. The result is a perfect blend of soft, colored light with a sharply defined beam at the center.
Spot With Gobos
The spotlight source is a bright 90W COB LED. Two gobo wheels provide a range of patterns. One wheel can rotate while the other remains static. Both gobo wheels can be layered to create new, fascinating projections. The rotating gobos can be swapped out easily without tools.
Prism Adds Variety
The prism produces further variations by tripling the image and can also rotate. Sharpness is set via DMX, and the focus is motorized. Spot colors come from a color wheel with seven dichroic color filters. Two-color effects are possible as well — the color wheel can be positioned in intermediate steps.
A highlight is a three-color rotating gobo that, combined with different colors, generates intriguing color effects.
Washlight
The wash LEDs are based on red, green, blue, white, amber and UV. From these you can mix countless color shades — from punchy hues and pastels to rich yellows and oranges.
The ultraviolet light not only produces the popular blacklight effect, it’s also an excellent mixing color. The beam angle of the soft wash light is 20 degrees.
Eurolite - Lighting Technology In Great Variety!
Features
- Eurolite Hybrid Moving-Head Spot/Wash COB
- Type: LED TMH-H90
- Powerful spotlight & full-featured washlight in one unit
- Positioning within 540° PAN and 200° TILT
- Precise positioning thanks to 16-bit resolution of PAN/TILT movement
- Rotating 3-facet prism with variable speed
- Strobe effect with 2-30 flashes per second
- Electronic dimmer (0-100%)
- Automatic position correction
- 1 x 90W COB LED (Chip-on-board) Cool White (CW)
- 6 x 10W high-power 6-in-1 HCL RGBWA/UV LEDs (homogeneous color mixing)
- Color wheel: 1 x 7 dichroic colors and open
- Rainbow effect with variable speed in both directions
- Gobo wheel with static gobos, 7 gobos and open
- Shake effect
- Gobo wheel with rotating gobos, 6 gobos and open
- Interchangeable gobos
- Slot-in gobo system for changing gobos without tools
- Built-in show programs
- Operable in 25-channel DMX mode
- Cooling: fan
- Control
Stand-alone
DMX
Sound-activated control via microphone
Master/Slave function
QuickDMX via USB (optional)
W-DMX by Wireless Solution via USB (optional)
CRMX by LumenRadio via USB (optional) - Preprogrammed for Light Captain
- Flicker-free
- Effect: gobo effect
- With a beam angle of 13°
- Multicolor LCD display for easy operation
- Weight: 6.5 kg
- Dimensions (W x D x H): 25 x 22 x 36 cm
- Color: White
Technical Data
- Power supply: 100-240 V AC, 50/60 Hz
- Total power consumption: 135 W
- LED: 1 x 90 W COB (Chip-on-board) Cool White (CW)
- 6 x 10 W high-power 6-in-1 HCL RGBWA/UV LEDs (homogeneous color mixing)
- Ingress protection: IP20
- Safety class: Class I
- Power connection: power input via P-Con (blue); built-in version with power cable and mains plug (included)
- Fuse: 5 x 20 mm, T 2 A replaceable fuse
- Lamp type: LED lamp
- Max. tilt movement (TILT): Precise positioning (16-bit resolution) 200° Auto-position correction (feedback)
- Max. pan movement (PAN): Precise positioning (16-bit resolution) 540° Auto-position correction (feedback)
- Flash rate: 2 - 30 Hz
- Features
3-fold prism
Gobo wheel with rotating gobos, single slot
Gobo wheel with static gobos
Motorized focus
Color wheel - Color generation: Color wheel 1 x 7 dichroic colors and open
- DMX channels: 25
- DMX input: 3-pin XLR (M) built-in version
- DMX output: 3-pin XLR (W) built-in version
- Beam angle: 13°
- Beam angle (1/2 Peak): Spot 13°
- Wash effect 20°
- Beam angle (1/10 Peak): Wash effect 38°
- Display type: Multicolor LCD display
Scope of delivery
- 1 x Eurolite LED TMH-H90 Hybrid Moving-Head Spot/Wash COB
- 1 x user manual
- 1 x power cable
- 1 x omega bracket
- 1 x safety cable eyelet
Specification
- Product number 00117225
- DMX interface Ja
- Colour Schwarz
- Light source power (Watts) 135
- Colour spectrum RGBWA/UV
- IP rating IP20
