Showlite HDO-16 Hybrid DMX Controller

  • DMX controller, 192 DMX channels, 16 channel faders, controls also LED devices, 6 programmable chasers, max. 240 scene memories (30 banks of 8 storage spaces each), strobe mode
  • 16 CHANNEL MODE: For up to 12 DMX-capable devices with max. 16 channels each, channel faders control the brightness of the individual channels, main faders function as speed and fade time faders
  • COLOR MODE: For up to 16 DMX-capable fixtures, DMX range: address 193 to 256, either RGB or RGBW spotlights can be used, channel faders control the color of the individual channels
  • TECHNICAL DATA: DMX output: 3-pin XLR, DMX input: 3-pin XLR, fader path: 6 cm, audio input: internal microphone, 19" width for rack mounting
  • Height for rack mounting: 3 HE, housing completely made out of metal, power supply included, dimensions (WxHxD): 482 x 76 x 175 mm, weight: 2.4 kg
Showlite
Variants (2)
Showlite LDO-10 MKII FS LED DMX Operator
Showlite DMX controller Master Pro USB
Showlite LDO-10 MKII FS LED DMX Operator Showlite LDO-10 MKII FS LED DMX Operator Showlite LDO-10 MKII FS LED DMX Operator
Showlite LDO-10 MKII FS LED DMX Operator
  • DMX controller, compatible with many lighting systems from e.g. Showlite, Involight or Eurolite KLS systems, 6 DMX fixture modes (selectable by switch), 12 preset programs
  • 12 user programs (each consisting of 12 scenes), programs each controlled automatically or by music, 4 x color controls with 12 colors each, 4 x brightness controls, master brightness control
  • Speed control, fader control for crossfade speed, strobe speed control, function keys: Blackout, TAP/Tempo, Auto, Music and Strobe
  • USB connection (only for software updates), connection for foot switch (6.3 mm jack), DMX output: 3-pin XLR, audio input: internal microphone or line input (6.3 mm jack)
  • Non-slip rubber feet, complete metal housing, Power supply: DC 9V, 300 mA, 2 hanging holes for wall mounting on the back side, dimensions incl. controller (WxHxD): 24 x 7 x 14 cm, weight: 1.1 kg
76,90 €
Showlite DMX controller Master Pro USB Showlite DMX controller Master Pro USB Showlite DMX controller Master Pro USB
Showlite DMX controller Master Pro USB
  • DMX controller, 192 DMX channels, USB port for data storage on USB stick, up to 12 DMX-compatible devices with max. 16 channels, including LED devices controls
  • max. 240 scene memory (30 banks of 8 memories), 6 programmable Chaser, joystick device control (tilt / pan), 8 channel faders with two pages (Page A: Ch 1-8, Page B: Ch 9-16)
  • 2 faders for "Wait Time" and "Fade Time" control the scene changes with chasers, 2 x display with 8 characters, integrated control for Fog Machine, DMX output: 3-pin XLR
  • Midi Input: 5-pin standard interface, USB connector: Type A, Audio input: built-in microphone or line input (RCA), Power Supply: DC 9V, 300 mA
  • 19"/ 3U, dimensions: 482 x 134 x 73 mm, weight: 1.5 kg, including power adapter and user manual
129,99
108,40 €
-13,4 %
149,00
Article reduced to 30.04.2021 /
Bestprice

Free shipping (DE) inkl. VAT.

In stock - immediately available
Delivery time 2 - 4 days
or
Delivery on Tuesday, 13.04.2021, if you order within  with Express delivery.
Finance from 10,75 € per month Product number: 00069094

Hybrid DMX controller with first-class features!

The Showlite HDO-16 provides foolproof control of LED spotlights on small stages, events, clubs or in theaters. The hybrid DMX controller allows the control of up to 16 DMX-capable devices. Self-created settings can be saved and recalled on a total of 240 storage spaces. And as a special highlight, it has a unique color mode that makes operating it a child's play.

16-channel mode
In "Normal" mode, up to 12 spotlights with 16 channels each can be controlled. The two large faders "Speed/Master" and "Fade Time/Strobe" serve as control options for the speed of the scene change or the fade transitions from one scene to the next.

Color mode
In color mode, a total of 16 spotlights of 3 channels each (4 channels in RGBW mode) can be controlled directly with the color faders on channels 193 to 256. The whole thing works with RGB or RGBW devices; mixing of different systems is not possible due to the channel assignment.

Scenes, banks and chases
The HDO-16 features a memory for 240 scenes (8 scenes on 30 banks), whose sequence can be programmed and played in a total of 6 different programs (chases). It is up to you whether the scene change is time-controlled, at the push of a button or music-controlled.

Can be combined with a second device
Since the HDO-16 has not only a DMX output, but also an input, two devices can be connected to each other. The big advantage here is that when changing scenes, you can fade back and forth between the settings of one console to the other.

Professionally simple!

Specification

Colour Black

Reviews

4.9/5.0
Based On 13 ratings
Show all reviews
5 Stars
12
4 Stars
1
3 Stars
0
2 Stars
0
1 Star
0
DMX Controller
Review from Massimiliano on 17.01.2020
Variant Showlite DMX controller Master Pro USB
This rating has been translated automatically. Original language flag from
 verified purchase
Looks like a good product.
Not yet in operation because of instructions written only in German.
Basic functions used by intuition.
Looking for manual written in Italian, but I see it hard.
I will have to settle for the one in English. Only in Italy they provide product instructions in a dozen other languages .
Very appreciable price for what the product offers and for the various models available on the market.
Great device. Does what it should. And very well.
Review from Norbert on 27.11.2019
Variant Showlite DMX controller Master Pro USB
This rating has been translated automatically. Original language flag from
 verified purchase
Prima Gerät. Tut was es soll. Und das sehr gut ........................................................................................................
I am very satisfied
Review from Markus on 06.05.2019
Variant Showlite DMX controller Master Pro USB
This rating has been translated automatically. Original language flag from
 verified purchase
Goods are top and can be operated prima. Delivery was fast ud reliable. Gladly again.
Guter Controller
Review from Rene on 15.02.2019
Variant Showlite DMX controller Master Pro USB
This rating has been translated automatically. Original language flag from
 verified purchase
Good controller
Sufficient for my LED headlights
Description a little bit poor, on YouTube there are better ones
Showlite DMX Controller Master Pro USB
Review from Florian on 06.01.2019
Variant Showlite DMX controller Master Pro USB
This rating has been translated automatically. Original language flag from
 verified purchase
Super product, can not complain, however, the expected delivery date was not met by lengths!
